# DDR4 memory information in Linux

## Background

If you’ve built a PC desktop in the last few years, you’ve probably been exposed to the confusing array of DDR4 information when it comes to buying RAM.

What it comes down to is not all RAM is created equal. Once you get past pin size and memory capacity, you’ll have to filter down by speed. Speed isn’t a simple one-figure number - you may see a rated speed like 2400MHz, but you may also see another bunch of numbers like 16-16-16-39 indicating the necessary clock cycles to perform certain types of memory operations.

While JEDEC - the people behind the DDR4 standard - ratify the well-known speeds like 2400 they’ve been quite behind the desires of consumers and manufacturers, so Intel created Extreme Memory Profile (XMP). XMP lets the RAM tell the PC a faster set of timings and clock speed it can support and what voltage it needs to do that. Things get a little more complicated as these memory modules are qualified only for specific speeds on tested motherboards and CPU combinations. XMP knows nothing about that - head to the RAM’s Qualified Vendor List (QVL) to check it instead.

While all of this used to be only of interest to people wishing to “overclock” their systems, the latest Ryzen Zen 2 CPU’s like the 3900X really benefit from increasing the memory speeds as the “Infinity Fabric” interconnect between the chiplets and the outside world runs at the speed of the memory controller (at least initially). Any Zen 2 owner wanting to take full advantage of the CPU they have purchased will need to dig in.

Thankfully memory modules for some time have a little bit of persistent memory called Serial Presence Detect (SPD) on them. It is accessed over the “I2C/SMBus” device bus in your machine so your BIOS or other tools can find out what the manufacturer has rated them for as well as who manufactured the actual memory chips themselves, when, where, and using what kind of die/process.

## Reading the Serial Presence Detect

So given all that, what do you do to take a look at this info?

Well, on Windows, you can just fire up a tool like Thaiphoon Burner, click EEPROM in the menu and then Read SPD on SMBus… which gives you something like this:

MEMORY MODULE
Manufacturer
Crucial Technology
Series
Ballistix Sport LT Red
Part Number
BLS16G4D240FSE.16FBD
Serial Number
3982077Bh
JEDEC DIMM Label
16GB 2Rx8 PC4-2400R-UB0-11
Architecture
DDR4 SDRAM UDIMM
DDR4-2400R
Capacity
16 GB (16 components)
Organization
2048M x64 (2 ranks)
Register Model
N/A
Manufacturing Date
Undefined
Manufacturing Location
Boise, USA (SIG)
Revision / Raw Card
0000h / B0 (8 layers)
DRAM COMPONENTS
Manufacturer
Micron Technology
Part Number
D9TBH (MT40A1G8WE-083E:B)
Package
Standard Monolithic 78-ball FBGA
Die Density / Count
8 Gb B-die (Z01A / 20 nm) / 1 die
Composition
1024Mb x8 (64Mb x8 x 16 banks)
Clock Frequency
1200 MHz (0.833 ns)
Minimum Timing Delays
16-16-16-39-55
20T, 18T, 16T, 15T, 14T, 13T, 12T...
Supply Voltage
1.20 V
XMP Certified
1200 MHz / 16-16-16-39-55 / 1.20 V
XMP Extreme
Not programmed
SPD Revision
1.1 / September 2015
XMP Revision
2.0 / December 2013

You can then feed these values into something like DRAM Calculator for Ryzen to figure out good fast timings to enter into your BIOS.

If you Google around, you’ll find guides that tell you to run various modprobe, i2cdetect commands, and probably decode-dimms however…

DDR4 uses a different type of SPD memory chips. Linux support is new and incomplete.

Previously these chips were a type known as eeprom - electronically-erasable programmable read-only-memory (the previous tech was just known as eprom as you needed an ultraviolet box to wipe them through a little window on the top).

DDR4, however, has switched from the very dated eeprom technology to more popular flash memory.

So if you run those commands, you’ll likely find decode-dimms doesn’t tell you much at all. There are two possible scenarios:

1. It tells you no eeprom found meaning the existing eeprom driver can’t find your SPD, and you’re most likely going to need to obtain and load an alternative i2c driver.
2. It shows you some generic RAM information but says SPD is invalid, meaning i2c is communicating with the SPD, but Linux doesn’t understand the DDR4 flash eeprom. You need to set up the ee1004 driver.

## Identifying the right I2C bus

Either way, you’re going to need to get the i2c device number your SPD is connected to by way of i2cdetect, so run:

i2cdetect -l


Which will give you some output like this:

i2c-3   i2c         i915 gmbus dpd                          I2C adapter
i2c-1   i2c         i915 gmbus dpc                          I2C adapter
i2c-2   i2c         i915 gmbus dpb                          I2C adapter


The results are system-dependent, but you need to deduce which one your SPD is on. The Intel Z370 chipset my Linux box runs uses the SMBus I801 interface, so I need to make a note of i2c-0.

If you’re not sure, then it may be a process of elimination based on the names. i915 is the Intel onboard CPU graphic support, so it wouldn’t be that, and a quick Google also associated the DPDDC-E with that too. I’d probably also give some preference to SMBus adapter ones rather than I2C, but I couldn’t find any confirmation that this is always the case.

If you’re not sure which one, you can try dumping information from each to see if you can find the right-looking data using this command but changing 0 to the likely candidates to the i2c device number from the first column in i2cdetect -l.

i2cdetect -y 0


With any luck, it should look something like this. If all you see are -- then try another.

     0  1  2  3  4  5  6  7  8  9  a  b  c  d  e  f
00:          -- -- -- -- -- 08 -- -- -- -- -- -- --
10: -- -- -- -- 14 15 -- -- -- -- -- -- -- -- -- --
20: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
30: 30 31 -- -- 34 35 -- -- -- -- -- -- -- -- -- --
40: 40 -- -- -- 44 -- -- -- -- -- -- -- -- -- -- --
50: 50 51 52 53 -- -- -- -- -- -- -- -- -- -- -- --
60: -- -- -- -- -- -- -- -- -- -- 6a -- -- -- -- --
70: -- -- -- -- -- -- -- --


Now there’s a chance - especially if decode-dimms told you no eeprom found that you don’t actually have the i2c driver loaded. The i801 driver is compatible with many Intel chipsets. To load that, you can use:

modprobe i2c-i801


If you’re running an AMD CPU, you might get away with:

modprobe i2c-amd-mp2-pci


if your Linux is really up to date. If not check out the i2c-amd-mp2 repo for manual installation instructions.

You can also try running decode-dimms again, and hopefully, now you should see some generic memory information.

## Introducing ee1004

Now that you have i2c working and identified, you can move on to the ee1004 flash driver for DDR4.

If so then just typing:

modprobe ee1004


Should get you up and running. If so, you can skip the next section and go straight to registering the SPD devices.

If you don’t have the kernel module (Ubuntu 18 doesn’t have it), you will see an error like this one:

modprobe: FATAL: Module ee1004 not found in directory /lib/modules/...


and so you’ll need to install it…

## Installing latest ee1004 driver

So either you don’t have ee1004 or you need the latest. Let’s CURL it down from the maintainers site. I wouldn’t recommend building kernel drivers from untrusted sources but…

curl -O http://jdelvare.nerim.net/devel/lm-sensors/drivers/ee1004/Makefile
curl -O http://jdelvare.nerim.net/devel/lm-sensors/drivers/ee1004/ee1004.c
sudo make install


(If make doesn’t work, you’re going to need to install things like build-essentials etc., via apt or your package manager of choice).

Now that is compiled and copied into /lib/modules/.../kernel/drivers/misc/eeprom/ee1004.ko we need to load it. Now there’s a small chance your system already has the older eeprom driver loaded, so we’ll unload that as well, so it doesn’t interfere:

modprobe -r eeprom
modprobe ee1004


## Registering the SPD devices

OK, so you now have the ee1004 driver installed, and you can see the bus your SPD devices are on. There are just a few more steps to make sure ee1004 knows which SPD devices it’s supposed to be using.

Run the following command replacing 0 with the number after i2c- you identified as the bus your SPD devices are located on:

i2cdetect -y 0


Now this will dump out that basic I2C information we saw earlier. On my system, it looks like this:

     0  1  2  3  4  5  6  7  8  9  a  b  c  d  e  f
00:          -- -- -- -- -- 08 -- -- -- -- -- -- --
10: -- -- -- -- 14 15 -- -- -- -- -- -- -- -- -- --
20: -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --
30: 30 31 -- -- 34 35 -- -- -- -- -- -- -- -- -- --
40: 40 -- -- -- 44 -- -- -- -- -- -- -- -- -- -- --
50: 50 51 52 53 -- -- -- -- -- -- -- -- -- -- -- --
60: -- -- -- -- -- -- -- -- -- -- 6a -- -- -- -- --
70: -- -- -- -- -- -- -- --


Notice those ‘50 51 52 53 bytes? Those are my four DDR4 DIMM sticks, and we need to register those numbers with the ee1004 driver.

Note: I couldn’t find out if the numbers that are important or the location.

You can start by just registering one to see if it works (replace i2c-0 with your i2c device from the previous section and 0x50 with the bank number of your memory module you figured out in the chart above:

echo ee1004 0x50 > /sys/bus/i2c/devices/i2c-0/new_device


now run decode-dimms and, with any luck, you will see output like this:

Memory Serial Presence Detect Decoder
By Philip Edelbrock, Christian Zuckschwerdt, Burkart Lingner,
Jean Delvare, Trent Piepho and others

Decoding EEPROM: /sys/bus/i2c/drivers/ee1004/0-0050
Guessing DIMM is in                              bank 1

---=== SPD EEPROM Information ===---
EEPROM CRC of bytes 0-125                        OK (0x05EA)
# of bytes written to SDRAM EEPROM               384
Total number of bytes in EEPROM                  512
Fundamental Memory type                          DDR4 SDRAM
SPD Revision                                     1.1
Module Type                                      UDIMM
EEPROM CRC of bytes 128-253                      OK (0x27DE)


If it did not register correctly, you should de-register the bank with the command:

echo 0x51 /sys/bus/i2c/devices/i2c-0/delete_device


If it worked, go ahead and register the rest of your modules depending on what banks you have memory sticks in. For example, on my system, the complete registration is:

echo ee1004 0x50 > /sys/bus/i2c/devices/i2c-0/new_device
echo ee1004 0x51 > /sys/bus/i2c/devices/i2c-0/new_device
echo ee1004 0x52 > /sys/bus/i2c/devices/i2c-0/new_device
echo ee1004 0x53 > /sys/bus/i2c/devices/i2c-0/new_device


Now you can finally run

decode-dimms --side-by-side


And get to see timings, manufacturer, etc.

Decoding EEPROM                                  0-0050                0-0051                0-0052                0-0053
Guessing DIMM is in                              bank 1                bank 2                bank 3                bank 4

---=== SPD EEPROM Information ===---
EEPROM CRC of bytes 0-125                        OK (0x05EA)           OK (0x699E)           OK (0x05EA)           OK (0x699E)
# of bytes written to SDRAM EEPROM               384
Total number of bytes in EEPROM                  512
Fundamental Memory type                          DDR4 SDRAM
SPD Revision                                     1.1                   1.0                   1.1                   1.0
Module Type                                      UDIMM
EEPROM CRC of bytes 128-253                      OK (0x27DE)

---=== Memory Characteristics ===---
Maximum module speed                             2400 MHz (PC4-19200)
Size                                             16384 MB
Banks x Rows x Columns x Bits                    16 x 16 x 10 x 64
SDRAM Device Width                               8 bits
Ranks                                            2
Rank Mix                                         Symmetrical
AA-RCD-RP-RAS (cycles)                           16-16-16-39
Supported CAS Latencies                          20T, 18T, 16T, 15T, 14T, 13T, 12T, 11T, 10T, 9T

---=== Timings at Standard Speeds ===---
AA-RCD-RP-RAS (cycles) as DDR4-2400              16-16-16-39
AA-RCD-RP-RAS (cycles) as DDR4-2133              15-15-15-35
AA-RCD-RP-RAS (cycles) as DDR4-1866              13-13-13-30
AA-RCD-RP-RAS (cycles) as DDR4-1600              11-11-11-26

---=== Timing Parameters ===---
Minimum Cycle Time (tCKmin)                      0.833 ns
Maximum Cycle Time (tCKmax)                      1.600 ns              1.500 ns              1.600 ns              1.500 ns
Minimum CAS Latency Time (tAA)                   13.320 ns
Minimum RAS to CAS Delay (tRCD)                  13.320 ns
Minimum Row Precharge Delay (tRP)                13.320 ns
Minimum Active to Precharge Delay (tRAS)         32.000 ns
Minimum Active to Auto-Refresh Delay (tRC)       45.320 ns
Minimum Recovery Delay (tRFC1)                   350.000 ns
Minimum Recovery Delay (tRFC2)                   260.000 ns
Minimum Recovery Delay (tRFC4)                   160.000 ns
Minimum Four Activate Window Delay (tFAW)        21.000 ns
Minimum Row Active to Row Active Delay (tRRD_S)  3.299 ns
Minimum Row Active to Row Active Delay (tRRD_L)  4.900 ns
Minimum CAS to CAS Delay (tCCD_L)                5.000 ns
Minimum Write Recovery Time (tWR)                15.000 ns             N/A                   15.000 ns             N/A
Minimum Write to Read Time (tWTR_S)              2.500 ns              N/A                   2.500 ns              N/A
Minimum Write to Read Time (tWTR_L)              7.500 ns              N/A                   7.500 ns              N/A

---=== Other Information ===---
Package Type                                     Monolithic
Maximum Activate Count                           Unlimited
Post Package Repair                              Not supported
Module Nominal Voltage                           1.2 V
Thermal Sensor                                   No

---=== Physical Characteristics ===---
Module Height                                    32 mm
Module Thickness                                 2 mm front, 2 mm back
Module Reference Card                            B revision 0

---=== Manufacturer Data ===---
Module Manufacturer                              Crucial Technology
DRAM Manufacturer                                Micron Technology
Assembly Serial Number                           0x3982077B            0xA02071FC            0x3982077D            0xA02071AC


## Identifying die revisions

One of the things you don’t see here is the die version. If you’re overclocking, it is important to determine what timings and tweaks you can get at (right now, Micron E-die is the newest hotness after Samsung B-die had a good run).

Die is not part of the specification, and it seems from playing with Thaiphoon, it’s a bunch of matching bytes. I’m looking into putting together a small Linux script/binary that will identify them, but in the mean-time, you have two options if you need this extra info:

Either way, you’ll need to make a Thaiphoon-compatible hex dump (replacing 0-0050 with the i2c bus number followed by a dash then the memory bank number)

od -Ax -t x1 -v /sys/bus/i2c/drivers/ee1004/0-0050/eeprom


You’ll see some output like this which you should copy to the clipboard:

000000 23 11 0c 02 85 21 00 08 00 00 00 03 09 03 00 00
000010 00 00 07 0d fc 2b 00 00 6b 6b 6b 11 00 6b f0 0a
000020 20 08 00 05 00 a8 1b 28 28 00 78 00 14 3c 00 00
000030 00 00 00 00 00 00 00 00 00 00 00 00 16 36 16 36
000040 16 36 16 36 00 20 2b 0c 2b 0c 2b 0c 2b 0c 00 00
000050 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
000060 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
000070 00 00 00 00 00 00 9c b4 c9 c9 c9 c9 e7 d6 ea 05
000080 11 11 01 01 00 00 00 00 00 00 00 00 00 00 00 00
000090 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0000a0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0000b0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0000c0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0000d0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0000e0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0000f0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 de 27
000100 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
000110 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
000120 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
000130 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
000140 85 9b 00 00 00 39 82 07 7b 42 4c 53 31 36 47 34
000150 44 32 34 30 46 53 45 2e 31 36 46 42 44 00 80 2c
000160 00 44 50 41 47 48 34 47 30 30 31 ff 00 00 00 00
000170 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
000180 0c 4a 05 20 00 00 00 00 00 94 00 00 07 ff 3f 00
000190 00 6a 6a 6a 11 00 6b f0 0a 20 08 00 05 00 a8 1b
0001a0 28 00 00 00 00 00 00 00 00 cf b5 ca ca ca ca d6
0001b0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0001c0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0001d0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0001e0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
0001f0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00
000200


Now either:

1. Send it to a Windows-using friend who can run Thaiphoon
2. Run Thaiphoon via WINE (which should now work as it won’t need low-level hardware access to the SMBus)

Inside Thaiphoon in the File menu, you’ll see Import from Clipboard which should reveal a lot of information, including the DRAM Die Revision / Process Node you’re after.

If you want to read another individuals hex dumps on your Linux box decode-dimms can do that too:

decode-dimms -x myspd1.hex


Enjoy!

[)amien

# Revisiting my BBC Micro - display, speech & more

It’s been a while since I blogged about Revitalizing my BBC Micro. In that time, I’ve performed a few upgrades readers might find interesting.

## Display requirements

As useful as the tiny Amstrad CRT was, I wanted something bigger, brighter, and sharper. LCD is terrible for retro systems with blurry scaling attempting to draw images designed to take advantage of CRTs. Emulator authors spend significant effort trying to mimic CRT effects for an authentic retro feel - but the best option is to use a CRT.

Most machines in the 80s and early 90s were designed for TV compatibility and operated on a 15KHz horizontal refresh rate. People struggle to give away VGA CRT monitors but, they won’t work as they start at 31.5KHz. British machines, like mine, also use the PAL (UK) video system rather than the NTSC (USA) system - a display for me will need to handle both.

If all you need are 15KHz frequencies, then Sony PVM is the way to go. I also own an Amiga 1200 capable of some VGA modes, so it would be nice to have one CRT for everything. Multi-sync monitors can do both but were rare in the 90s and are even rarer now, combined with high shipping costs on CRTs in general, make them a prohibitive choice.

## Commodore 1942 CRT

Luckily for me a Commodore 1942 CRT “bi-sync” turned up on Craigslist just 15 minutes from my house! It was designed for the later Amiga models so, it does both 15KHz most of my machines can do and some VGA resolutions, perfect.

Connecting it to the BBC was a little trickier than I anticipated. That Amiga design means it expects the horizontal (HSYNC) and vertical sync (VSYNC) signals on two different pins to match the Amiga’s video port rather than the composite sync (CSYNC) all my RGB capable machines offer (Amiga excluded).

I experimented with connecting CSYNC to HSYNC and then to VSYNC, but both failed to resolve a stable display. Digging into the Motorola 6845 CRT controller chip that powers the Beeb reveals both VSYNC and HSYNC on pins 40 and 39, respectively. A quick snip of the RGB port’s unused 5v and sync pins let me repurpose them to HSYNC and VSYNC direct to the 6845. A stable but over-saturated picture was a welcome next step that didn’t need me to create a SYNC splitting circuit (I did that later to connect with my Spectrum +3).

The over-saturation is because the BBC Micro outputs either 0v or 5v - off or on - for each color. The Amiga monitor is analog and accepts any amount of color between 0v and 0.7v. I read guides on calculating the voltage drop, but it still looked saturated so, I kept increasing resistor values until I found values that looked right.

The final result made me smile. It looked better than the Microvitec CUB monitors our school had back in the day!

## Speech synthesis

Hearing Superior Software’s SPEECH package blurt out any phrase we cared to throw at it was a blown-away moment at school. I’ve always wondered what the official Acorn speech system was like, especially as every time I open the case empty sockets IC98 and IC99, call out for the Texas Instruments TMS5220 speech processor and associated TMS6100 voice synthesis memory.

The TMS5220 chip was a successor to that in Speak & Spell, Bally/Midway pinball machines, and some arcade games and is easy to come by. The TMS6100 was available in many variants, and the BBC commissioned some of their own, including one sampled by BBC news anchor Kenneth Kendall. This chip is rare, and the fact the TMS6100 is not a regular ROM means you can’t just burn a copy. Thankfully Simon Inns created an emulator which, can run on an ATMega32U2 to provide a drop-in replacement!

I obtained a TMS5220 and pre-built TMS6100 emulator board from Mark Haysman at RetroClinic - I can thoroughly recommend his services! (My SMT soldering skills are not up to this)

After inserting the two chips and powering nothing looks different. This command sequence however provides a good test mechanism:

REPEAT : SOUND -1,GET,0,0 : UNTIL 0

Pressing any key on the keyboard will cause the machine to say aloud the letter. It does, however, have some odd ideas about what the symbols on the keyboard are.

I will be experimenting with this more as I dig through the capabilities in the manual as it isn’t as easy to use as Superior Software’s Speech! which lets you type things like:

*SPEECH
*SAY Hello there.


## ROM experiments

My school had a single copy of the Advanced User Guide, so I felt privileged when the teacher would let me borrow it. On reflection, I doubt anyone else wanted to. Page 395 cryptically teases:

Up to 16 paged ROMS are therefore catered for, 4 of which are on the main circuit board.

So the OS supports 16 ROMs but, there are only physical sockets for 4 (IC52, IC88, IC100, and IC101). Typically BASIC and the disc filing system (DFS or ADFS) take two of them leaving, just two usable ROM sockets for expansion.

The schematics reveal IC76 is the ROM Select Latch and is a 74LS163 with four output pins giving sixteen possible combinations. As the OS and circuitry support sixteen, we need to find a way to connect them.

The Beeb supports either 8K (2764) or 16K (27128) ROMs and EPROMs. Later 64KB (27512) chips became available which are almost pin-compatible with the 27128 except:

27512 Pin 27127
A15 1 Vpp
A14 27 /PGM
/OE 22 /OE, Vpp

The /PGM and Vpp lines are for writing - an EPROM programmer will care about these but, our Beeb won’t.

The A14 and A15 lines are the address lines for accessing the higher memory. With them both low, the chip acts like a regular 16K (27128) chip. With A14 high, it looks to the next available 16K, with A15 high the next 16K, and with A14 and A15 high the final 16K.

We can combine four 16K ROM images into a single 64K file and flash it to our 27512. I did just this with my Signstek TL866A Universal USB programmer.

By connecting A14 and A15 to the IC76 address line C and D outputs, we have effectively given whatever socket we connect the ability to appear as four ROMs (because a single ROM can be paged in at a time).

The icing on the cake is that the Beeb sports a push-out section left of the keyboard (affectionately known as the “ashtray”). This area is where a zero insertion force - ZIF socket - could be mounted to allow a ROM to be dropped in without needing to crack open the case.

Now I need to figure out how to mount this ZIF socket in the ashtray hole - there aren’t any mounts. I suspect I’m going to need to make a PCB of some sort and put legs on it.

#### Parts list

• 28-pin ZIF socket
• 28-pin DIP socket 0.6” wide
• length of 28-way ribbon cable
• 2.54mm header pins (you need two)
• 2x female-to-female jumper wires

#### Creating the cable

1. Wire all pins from ZIF to DIP except for 1 & 27
2. Solder two header pins to 11 & 12 on IC76
3. Jumper ZIF pin 1 to 11 on IC76
4. Jumper ZIF pin 27 to 12 on IC76

Now insert a 27512 ROM flashed with four BBC ROMs of your choice, power up and type *HELP or *ROMS to see the images ready.

Check out alternatives for wiring up 64K ROMs or 32K SRAM chips from J.G. Harston

## Second processor via a Pi Zero

The Beeb has a bunch of expansion ports hidden underneath the machine - the most unusual one being the Tube expansion bus which allows for a 2nd processor, by way of FIFO buffers, that facilitated message-passing IPC for console, errors, data, and system calls.

Acorn produced expansions for the Tube, including:

• 6502 second processor allowing well-behaved unmodified programs to run faster
• Z80 for CP/M
• 80286 for DOS or GEM

These expansions are hard to come by as they don’t just feature the CPU but necessary additional isolation logic, memory and circuitry. David Banks developed PiTubeDirect to allow a Raspberry Pi to act as a second processor plugged into the Tube port by way of a 5V to 3.3V level shifter - I got mine from Kjell Sundby

The Raspberry Pi 3 can emulate these old processors at crazy speeds! 274MHz for the 6502, 112MHz for the Z80, 63MHz for the 80286, and even a 59MHz ARM2 (Acorn were using the Beeb to work on ARM prototypes)

What piqued my interest was using the Raspberry Pi Zero. It’s small enough to fit under the BBC Micro and yet remains plugged into the Tube port out of sight. Latency was a problem on the Zero given the lower ARM processor so, they ported the CPU emulation core… to the GPU!

The 6502 emulation is reliable and enabled me to run the 6502 Second Processor Elite. I need to try to get GEM running on it just for fun although, it’s a little trickier to find suitable disk images for Z80 and 80286 co-processor stuff.

[)amien

# Notes on Edward Tufte’s Presenting Data and Information

Here are my notes from today’s event by renowned statistician Edward Tufte – author of The Visual Display of Quantitative Information and Envisaging Information primarily for my own reference but perhaps of interest to others.

## A dramatic start

No announcement, no preamble. The lights went out, and a visually striking video showing a representation of music started. Conversations were immediately hushed, and devices put away. An effective technique to get attention and signal an absolute start.

## Charts and tables

• Sorting: Find a sort for your data that makes sense. Treat it as another axis, and don’t waste it with the alphabet.
• Sparse columns: Remove sparsely populated columns from tables. Special events should be specially annotated.
• Linking lines: Always annotate them to describe the interaction, prefer verbs over nouns from a taxonomy.

Information does not fit in a tree. The web is successful because Tim-Berners Lee understood this and made links the interconnectedness between content. “Vague, but exciting”

## Data

Content is not clean. Data that shows behaviour in a perfect way is likely manipulated.

Human beings over-detect clusters and conspiracies. They find links between unrelated events, especially in sequences (serial correlation). Sports commentators, given any series of scores, will develop a false narrative to explain it. They’ll find a reason for 7 wins in a row despite random data producing such sequences.

Self-monitoring is a farce because people can’t keep their score. Once something is measured, it becomes a target to be gamed and fudged as needed.

You can make many models to fit any given data. It may work well for past and current data, but how far it lasts is highly variable. This is referred to as shrinkage – no model lasts forever.

Big data is not a substitute for traditional data collection and analysis. Google famously thought this when they created Google Flu which tried to spot the spread of flu based on search terms. It has been seriously criticized by Forbes and the New York Times.

## Conflict

How many nice comments wiped out a bad one? Ten… a hundred?

Evil exists in the world, but it probably does not exist in your day-to-day life.

## A deck of slides

A deck is inefficient. It is easy for the presenter but hard for the audience who are waiting for something they can use. “A diamond in the swamp” Slow reveals further reduce the information density, and people will check-out when it gets low.

Prefer spatially adjacent data (a document) over temporally stacked (slides). The often-cited limit of 7±2 items was for temporal retention, so limiting a page to this number of items is the opposite of what that research was telling us. We can cope with much more data if it is all on-page together.

## Meetings and presentations

Do not be afraid of paper.

Prepare a document in advance but do not send it and instead spend 30 minutes at the start of the meeting reading it in silence (known as a study hall). People can read faster than you can talk as well as go back and forth as needed, skipping what they already know, and latecomers are less disruptive. Amazon is famously using this with its 6-page narrative memo system.

Never go meta in your presentation – stick to the content. Respect your audience and do not presume to know them, or you may find yourself pandering or having low expectations. Instead, present the data to the best of your ability. Many complicated things are explained to millions of people all the time. You can’t teach if you have low expectations. Negativity and positivity are self-fulfilling.

Does your audience understand and trust you? Credibility is eroded not just by lying but by cherry-picking. Evidence of cherry-picking includes data too good to be true and hiding the source of the data behind excuses such as copyright, proprietary, or secrets. Why would a conclusion be open when the data needs to be secret? It’s likely a misrepresentation of the data for their own means.

Note a few words when somebody asks you a question to make sure your answer stays on topic. If you don’t know the answer be honest and suggest where you would start looking for the answer. Never heckle or waste time correcting minutiae.

### Doctors trip

A trip to the Doctor’s office is a presentation. Write down your list before you go in. Make them listen because they normally interrupt after 22 seconds and consider each item individually. You’ll give up before you reach the end of your list this way, and they may not see the connected pattern of the whole.

## Documents

Every document needs an abstract. It should spell out as simply as possible:

1. What the problem is
2. Who cares
3. What the solution is

If you can’t write this, then you’re not saying anything.

### Latex

Real scientists use Latex. There are thousands of templates including, official ones for well-known journals. Online tools like Overleaf can reduce the barrier to entry. Latex code appears like this:

\title{My presentation matters}
\begin{document}
\section*{Introduction}
Sample of Latex
`

R is another alternative considered hard even by people who use Latex.

We are taught to read to extract facts to pass exams at school. We need to practice reading for enjoyment, reading to spot new information, to extract what we want, to form new opinions and ideas, to loot & hack.

Immediately skip words you don’t understand: there won’t be a test – you’re not at school.

## Design

Design does not belong to ‘other people’. Support thinking with analytical design and do whatever it takes to explain the data.

Why do bird books use illustrations? Because the authors want to help you spot the birds and using art they exaggerate the differences as well as produce a generic version of the bird.

Nature magazine has some of the best-designed visualizations around. Openness, pride and space constraints all help. (DNA only got 1.5 pages) The New York Times also often produces interesting visualizations of data.

## User interface

Use the ideas proven by large successful sites on the web. Do not be swayed by arguments that your users won’t understand. Millions of users already do.

Touch is the next generation of user-interface. It allows the chrome (interface junk) to be jettisoned. No more scroll-bars, no buttons, no cursor, no zoom. Pure information experiences came not from academia, finance or medical but consumer space.

The future of interface design… is information design. Edward Tufte – Seattle, August 4 2015

The original UI metaphors at Xerox Parc on the Alto were around a single document. Instead, we have application-owned silos of data. The elegance was lost because companies want to control the content you create with their tools. They isolate your content so they can profit.

Hierarchies are still used for web design because it mimics the organization paying the bill. They see themselves this way and do not focus on how and what their customers need. Famous examples include the Treasury Department burying tax forms 7 levels deep despite being a top user request and the XKCD strip about University web sites. People on the inside have a skewed perspective of what the outside is.

The density of user interfaces is increasing. This allows for richer visualizations, especially when combined with animation or video. It is hard to get right.

[)amien

# Quality of SSL protection for US financial institutions

Troy Hunt put together a list of top Australian banks and their SSL rating using the Qualys SSL Server Test that reveals the somewhat depressing state of SSL security of various banks down-under.

This got me wondering how US financial institutions stack up, and I thought I’d share:

Update Nov 2015: Lots of progress by many of the institutions with the exceptions of KeyBank still showing Poodle vulnerability, Union needing to support newer tech, Mint lacking overall considering they’re a tech company and Citibank being lame for blacklisting SSL Labs.

[)amien
